| Cutting width | Maximum width of cut (meters) | 7.98 |
| HP requirement | Minimum HP requirement of tractor | 120 |
| Weight | Weight of machine (KG) | 3034 |
| Cutting height | Min to max cutting height (mm) | 25-356 |
| Cutting capacity | Maximum diameter of material (mm) | 50 |
| Overall width | Maximum external width (meters) | 8.15 |
| Overall length | Maximum external length (meters) | 5.13 |
| Transport width | Width when folded for transport (meters) | 2.98 |
| Transport height | Height when folded for transport (meters) | 3.76 |
| PTO speed | max RPM of PTO Shaft | 1,000 |
| Gearbox rating | Power Divider (hp) | 220 |
| | Centre Gearbox (rpm) | 800 |
| | Wing Gearboxes (rpm) | 974 outer, 812 inner |
| No of blades | Number of heat treated up draft blades | 20 |
| Tip Speed | Wings & Centre Deck | 4682m per min |
| Rotor speed | Wings & Centre Deck | 4614 rpm |
| Blade overlap | Distance blades overlap when running (mm) | 154 |
| Hydraulic wing flex | Degrees of wing travel in work | 45° up, 15° down |
| No of wheels | Number of wheels | 8 or 6 |
| Skid shoes | Replacable skid shoes | Standard |
